OKM eXp 6000 Professional Plus

Description

This is the world’s first 3d ground scanner that utilizes OKM’s newly invented Telescopic Probe that can be extended from 50 to 120 cm. The very unique multilingual user interface and wireless measuring probes allow easy operation. The eXp 6000 uses Visualizer 3D software to analyze graphical scan images for detected objects and to determine the depth and dimension of underground targets like ancient artifacts, precious treasures, and historical items. The eXp 6000 ground scanner and 3d metal detector are designed for treasure hunters, archaeologists, prospectors, and gold seekers to locate buried artifacts, historical items, lost treasures, and hidden objects:

• precious metallic objects like gold, silver, copper, and bronze
• hidden non-metallic structures such as ancient tombs, caves, walls, foundations, statues, chambers and sepulchers
• natural gold minerals
• valuable artifacts and lost treasure
• battlefield artifacts, historic settlements, and ancient sanctuaries

All components of this geophysical measuring instrument are wireless. The measuring probes of the eXp 6000 are using WiFi to establish a wireless data connection to the 3d detector. Assembling the unit is as easy as 1-2-3. The ground scanning system mainly consists of the following parts:

• Control Unit with touch screen, multilingual GUI (graphical user interface) in different layouts, automatic brightness control and GPS (can be activated by the user)
• Telescopic Rod Assembly to connect one of the following measuring probes:
  • Telescopic Probe: This very new invented measuring probe can be extended from 50 to 120 cm and is perfectly designated to scan even large areas as well as small fields. From now on the operator don’t need to carry around many probes in different sizes.
  • Super Sensor: This specialized ground measuring probe is one of the best ground scanner accessories on the market. By using this antenna discrimination and pinpointing of buried objects is possible with ease.
  • Tunnel Sensor: This measuring probe can be mounted to the 3d metal detector to detect hidden tunnels, chambers, cellars, shelters, caves, and many other cavernous targets.
  • LiveStream Sensor: This ground scanning probe will stream measuring data directly onto the display of the eXp 6000 to see underground objects “live”. So the operator of the 3d ground scanner can quickly survey a large area to find potential targets underground.

Delivery Scope

Technical Specifications

Control Unit

• Dimensions (H x W x D): 120 x 210 x 280 mm
• Weight: approx. 2.34 kg
• Voltage: 11.8 – 19 VDC, 50 W maximal
• Safety Class: IP40
• Operating Time (full charged, 25 °C): approx. 4 hours
• Operating Temperature: -10 °C – 50 °C
• Display: 6.5” Diagonal, 1024 x 768 Pixel TFT Color, 650 cd/qm
• Processing Unit: QuadCore AMD @ 2GHz, OpenGL4.2 HD Radeon GPU
• Working Memory (RAM): 4 GB Kingston HyperX
• Data Memory: 8 GB SDCard, Class 10
• Feedback: acoustic, visual
• Storage temperature: -20 °C – 60 °C
• Air humidity: 5 % – 75 %
• Waterproof: No
• Data Transmission Technology: WiFi 802.11n a/b/g, MIMO 2×2
• Data Transmission Rate: 11 Mbps – 54 Mbps
• Operation Distance (line of sight to telescopic rod): max. 4 m

Telescopic Rod

• Dimensions (H x W x L): 210 x 135 x 680 – 1340 mm
• Weight: about 1,76 kg
• Voltage: 11.8 – 19 VDC, 22 W maximal
• Safety Class: IP40
• Operating Time (full charged, 25 °C): approx. 5 hours
• Operating Temperature: -10 °C – 50 °C
• Processing Unit: ARM Cortex M0+ @ 48 MHz
• Working Memory (RAM): 32 KB
• Data Memory: 256 KB
• Storage temperature: -20 °C – 60 °C
• Air humidity: 5 % – 75 %
• Waterproof: No
• Data Transmission Technology: WiFi 802.11n a/b/g
• Data Transmission Rate: 11 Mbps – 54 Mbps
• Operation Distance: (line of sight to control unit): max. 4 m

Super Sensor

• Length: 950 mm
• Weight: approx. 1.0 kg
• Receiver: Dual / Hi-Gain – Vertical – Geophysical Phase Reader – EMSR
• Sensor technology: SCMI-15-D

Telescopic Probe

• Length: 820 – 1240 mm
• Weight: approx. 1.04 kg
• Receiver: Dual Geophysical Phase Reader – EMSR
• Sensor technology: SCMI-15-D

Tunnel Sensor

• Length: 500 mm
• Weight: approx. 0.76 kg
• Receiver: Dual Geophysical Phase Reader – EMSR
• Sensor technology: SCMI-15-D

Live-Stream Sensor

• Length: 600 mm
• Weight: approx 0.92 kg
• Receiver: Hexa Geophysical Phase Reader – EMSR
• Sensor technology: SCMI-15-D

GPS Receiver

• Dimensions (L x W x H): 50 x 55 x 27 mm
• Weight: about 60 g
• Input voltage: 5 V DC
• Input current (maximum): 450 mA
• Input current (typical): 50 mA
• Refresh rate: 1 s
• Cold start: < 40 s
• Warm start: < 30 s
• Horizontal Position Accuracy (most cases, outdoor): 2,7 m
• Horizontal Position Accuracy (free view, clear sky): 0,9 m

The technical data are average values. Minor deviations are possible during operation.
